GPS - Systems

Features

  • Antenna splitter for up to four receivers connected to one antenna is available
  • Time Capture Inputs
  • Asynchronous Serial Ports
  • Pulse and Frequency Outputs
  • DCF77 Emulation
  • Programmable pulse
  • Time Code outputs
  • Time Zone and Daylight Saving
  • Redundand Power Supply


GPS Satellite Receiver with LC display and
control elements in 19 inch/3U housing

GPS - Satellite Receiver in modular metal case

Meinberg GPS solutions are available in a modular 3U 19" rack mount housing and can be equipped with a wide range of output modules, redundant power supplies or even redundant receivers. If you need an individual offer, please contact us. We will design a system configuration for your specific time and frequency needs, based on your specifications and requirements.

GPS systems built up in rackmount slimline modular case

GPS - Satellite Receiver in MultiPac case

GPS170MP is a set of equipment composed of a GPS satellite controlled clock together with a power supply unit Mean Well T-60B, both installed in a metal desktop case (MULTIPAC) and ready to operate. The interfaces and input/ output signals provided by the GPS receiver are accessible via connectors in the rear and the front panel of the case.

Options:
  • Programmable pulse
  • IRIG Time code AM / DCLS (modulated / unmodulated)

GPS - Satellite Receivers with integrated time code generator for rail mounting

GPS - Satellite Receiver in railmount form factor

The GPS164xHS is designed for mounting on a DIN rail. The front panel integrates five LED indicators, a hidden push button, an eight-pole terminal block, three DSUB- and three BNC-connectors. The receiver is connected to the antenna/converter unit by a 50 O-coaxial cable with length up to 300 m (when using RG58 cable). It is possible to connect up to four receivers to one antenna by using an optional antenna diplexer.

The integrated power supply is available as an AC (GPS164AHS) or two DC variants (GPS164DHS/19-72VDC and GPS164DAHS/100-240VDC). The build-in time code generator provides modulated and un-modulated IRIG-B or AFNOR outputs.
